DDBC1200 Signal Dimmer Controller

Name: DDBC1200 Signal Dimmer Controller
Brand: PHOTONITY SOLUTIONS
Price: 2500 INR
Availability: InStock

Price 2500 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

DDBC1200 Signal Dimmer Controller Specification

Mounting Type
DIN Rail Mountable

Pole Type
Single Pole

Weight
610g

Surface Finish
Matte finish

Thickness
39 mm

Usage & Applications
Lighting control and dimming in commercial and residential installations

Features
Multi-channel control, manual override, overload protection

Product Type
Signal Dimmer Controller

Material
Polycarbonate body with electronic components

Rated Power
1200W

Length
170 mm

Voltage
230V AC

Lighting
Compatible with incandescent and dimmable electronic ballasts

Input Voltage
220-240V AC, 50Hz

Working Temperature
0C to 50C

Rated Current
5.2A max per channel

Socket
Screw terminal

Color
Grey

Height
129 mm

Protection
Short circuit and over-temperature protection

Control Signal Input
0/1-10V analog / DALI / DMX512

Communication Interface
RS485/232 ports

Relative Humidity
10% to 90% non-condensing

Number of Channels
12 channels

Storage Temperature
-10C to 60C

IP Rating
IP20

Dimming Mode
Trailing edge (phase cut)

Response Time
<500ms

About DDBC1200 Signal Dimmer Controller

Experience dazzling illumination control with the DDBC1200 Signal Dimmer Controller-a peerless solution for commercial and residential lighting. Equipped with 12 unassailable channels, this sizzling device accommodates 0/1-10V analog, DALI, and DMX512 inputs, ensuring compatibility with diverse systems. Take advantage of instant checkout and a matte-finished, polycarbonate body designed for reliable performance. With robust protection against short circuits and overheating, plus ultra-fast response time (<500ms), it delivers unbeatable, smooth dimming. Mount effortlessly on a DIN rail and redefine lighting control with masterful ease.

Superior Control for Diverse Lighting Needs

The DDBC1200 Signal Dimmer Controller is tailored for both specific and general lighting uses. Its 12-channel, single pole design ensures multi-zone control, making it ideal for large offices, retail establishments, and homes. The device's trailing edge dimming, manual override, and overload protection features ensure seamless operation. Compatible with both incandescent and dimmable electronic ballasts, it elevates any space with refined brightness management and exceptional reliability.

Sample Provision and Certification Assurance

Samples of the DDBC1200 Signal Dimmer Controller are available upon request, packaged securely to guarantee safe delivery. Certified to meet safety and performance standards, this product supports your project proposals, ensuring confidence from the initial sample onward. Proposal amounts can be discussed, and samples are delivered promptly nationwide, meeting the expectations of suppliers, traders, and distributors across India seeking peerless lighting solutions.

FAQ's of DDBC1200 Signal Dimmer Controller:

Q: How is the DDBC1200 Signal Dimmer Controller typically used?

A: The DDBC1200 is widely used to control and dim lighting in both commercial and residential settings, allowing precise adjustment of light intensity across 12 independent zones.

Q: What are the key features of this dimmer controller?

A: Key features include multi-channel (12 channels) control, support for multiple control signals (0/1-10V analog, DALI, DMX512), trailing edge dimming, manual override, overload and short circuit protection, and a matte polycarbonate body.

Q: Where can the DDBC1200 be installed?

A: Designed for DIN rail mounting, the DDBC1200 can be easily installed in electrical control panels commonly found in offices, retail spaces, and residential complexes.

Q: When should I request a sample, and what is the packaging standard?

A: You can request a sample for evaluation during your project planning stage. Each sample is packaged securely to prevent damage during transit and ensure its condition upon delivery.

Q: What process is followed during ordering and proposal discussions?

A: Upon proposal submission and agreement on the amount, the product is dispatched with full documentation and customer support, providing a seamless procurement process for distributors, suppliers, and service providers.

Q: What are the benefits of using this signal dimmer controller?

A: Using the DDBC1200 provides precise, reliable, and energy-efficient lighting management, with robust safety features and compatibility with a broad range of dimmable lighting systems.
